数据集格式：Pascal VOC格式+YOLO格式(不包含分割路径的txt文件，仅仅包含jpg图片以及对应的VOC格式xml文件和yolo格式txt文件)

图片数量(jpg文件个数)：4864

标注数量(xml文件个数)：4864

标注数量(txt文件个数)：4864

标注类别数：21

所在github仓库：firc-dataset

标注类别名称(注意yolo格式类别顺序不和这个对应，而以labels文件夹classes.txt为准):["Arrester body","Arrester voltage equalizing ring","Breaker","Breaker connector","Breaker support insulator","Casing connector","Casing general hat","Casing porcelain sleeve","Casing pressure equalizing ring","Current transformer connector","Current transformer general cap","Current transformer head","Current transformer porcelain sleeve","Current transformer secondary tank","Current transformer voltage equalizing ring","Knife blade","Knife gate connector","Knife gate fixing pin","Knife gate support insulator","Voltage transformer body","Voltage transformer secondary tank"]

每个类别标注的框数：

Arrester body (避雷器本体) 框数 = 1288

Arrester voltage equalizing ring (避雷器均压环) 框数 = 1271

Breaker (断路器) 框数 = 1781

Breaker connector (断路器连接器) 框数 = 3264

Breaker support insulator (断路器支撑绝缘子) 框数 = 1654

Casing connector (套管连接器) 框数 = 469

Casing general hat (套管通用帽) 框数 = 510

Casing porcelain sleeve (套管瓷套) 框数 = 1208

Casing pressure equalizing ring (套管均压环) 框数 = 709

Current transformer connector (电流互感器连接器) 框数 = 2284

Current transformer general cap (电流互感器通用帽) 框数 = 515

Current transformer head (电流互感器头部) 框数 = 1066

Current transformer porcelain sleeve (电流互感器瓷套) 框数 = 1208

Current transformer secondary tank (电流互感器二次接线盒) 框数 = 147

Current transformer voltage equalizing ring (电流互感器均压环) 框数 = 6

Knife blade (刀闸动触头) 框数 = 1289

Knife gate connector (刀闸连接器) 框数 = 2429

Knife gate fixing pin (刀闸固定销) 框数 = 289

Knife gate support insulator (刀闸支撑绝缘子) 框数 = 2410

Voltage transformer body (电压互感器本体) 框数 = 948

Voltage transformer secondary tank (电压互感器二次接线盒) 框数 = 910

总框数：25655

图片分辨率：640x640

使用标注工具：labelImg

标注规则：对类别进行画矩形框

重要说明：暂无

特别声明：本数据集不对训练的模型或者权重文件精度作任何保证

图片预览：

标注例子：
